Malimo Malitronic Maliwatt Nonwoven Fabric Stitch Bonding Machine Raschel Jacquard machine
Product Application
The machine is used for the sewing processing of nonwoven fabric, to increase its fastness and toughness, which is widely used in the fiele of health care, clothing lining.
Characteristic
Feed, stretch. warp, take-up are all controlled by servo motor, good synchronization. We can choose 1 or 2 bars. With 2 bars, the fabric has a significant improvement in stability, strength, anti-loose and sliding resistance.
Main tech data
| Needle type |
Compound needle |
Max speed |
1800RPM |
| Work width |
2.4m, 2.9m,3.6m,4.4m |
Pattern device |
Pattern disk |
| Gauge |
E5,E9,E12,E18,E22 |
Yarn let-off drive |
EBA electronic year let-off |
| Main motor power |
2.2kw, 5.5kw |
Frbric take-up |
Eletronic take-up device |
| Guide bar NO. |
1,2 |
Eletronic batching deviceBatching device |
Eletronic batching device |
| Main drive |
Eccentric linkage |
Feed device |
Eletronic feed |
Main Features
1. Main motor is driven by three-phase current at variable speed.
2. Electric equipment abides by EN60204 (machine security) and VBG4
(supervising accidents prevented).
3. Operating interface system is self-developed.
4. Customer using voltage: 400V (±10%), third level/ Neutral conductor/
ground connection, 50Hz.
5. Main fuse and main power can meet with the requirements of the operating instructions.
6. Customers should make sure the machine has connected with grounding protection to avoid the leakage current.
7. Customer should be informed if machine is connected to the public low-voltage power supply.
