Working width / Gauge

• 2540 mm = 100”
• 3505 mm = 138″
• 5334 mm = 210″
• E18, E22, E24

Knock-over comb bar distance:

1–12 mm, continuously adjust able. Central trick plate distance readjustment

Bars / knitting elements

• Two needle bars with latch needle units, two knock-over comb bars and two moveable stitch comb bars, 6 ground bars, GB3 and GB4 stitch forming on both needle bars
• Option: individual needle bars

Warp beam support: 6 × 812 mm = 32″ (free-standing)

GrandStar®(GrandStar COMMAND SYSTEM)

Operator interface to configure, control and adjust the electronic functionality of the machine

Yarn Iet-off device

For each completely mounted warp beam position: one electronically controlled yarn Iet-off drive

Fabric take-up

Electronically regulated fabric take-up, driven by geared motor, consisting of four rollers.

Batching device

Separate rolling device

Pattern drive

• EN-drive with seven electronic guide bar drives.
• shog distance: ground 18 mm, pile 25 mm
• Optional for Electronic guide bar drive EL, all guide bars shog up to 150 mm

Electrical equipment

• Speed-regulated drive, total connected load of the machine: 7.5 KW
• Voltage: 380V±10% three-phase power supply, main power cord requirements: not less than 4m㎡ three-phase four-core power cord, ground wire not less than 6m㎡

Oil supply

Heating and cooling by means of circulating air heat exchanger, filter with dirt-monitoring system

Equipment working conditions

• Temperature 25℃±3℃, humidity 65%±10%
• Floor pressure: 2000-4000KG/㎡
